ASTM A106 Grade C Carbon Steel Pipe
ASTM A106 Grade C Carbon Steel Pipe
Tags:
Specifications and Dimensions

Outer Diameter: 10.29 - 609.60 mm ( NPS ⅛″ - NPS 24″ )

Wall Thickness: 1.24 - 59.54 mm ( Sch 10 - 160, STD, XS, XXS )

Length: 3,000.0 - 12,000.0 mm

Customization is available.

Standard: ASTM A106 / A106M

Grade: Grade C

All products undergo rigorous inspection and testing before leaving the factory, and mill test certificates are provided.

The third party test (such as SGS, BV, etc.) can be added as required.

Rust Removal,Painting,Coating

Custom dimensions, precision cutting, threading, bending, bevel cutting, heat treatment, etc

Packaging: Steel-strap bundling, standard export packaging for ocean freight, or packaging as required.

MOQ: 5 tons.

Delivery Time: 15 - 20 days

Payment Terms: T/T, L/C.

You can contact us in the following ways to learn more about our products.
info@chinacarbonsteel.com
+8615837212056
Get a Quote

Related Technical Resources

ASTM A106 Seamless Carbon Steel Pipe Dimensions.pdf

What is ASTM A106 Grade C Carbon Steel Pipe?

ASTM A106 Grade C is a seamless carbon steel pipe that complies with the ASTM A106/A106M standard and is specifically designed for high-temperature, high-pressure industrial piping applications.

Compared to A106 Grade A/B, A106 Grade C has higher tensile strength and yield strength, making it suitable for high-temperature piping projects subject to higher mechanical loads. It is widely used in power generation, petrochemical, refining, and boiler piping systems to transport steam, petroleum, and natural gas under high-temperature and high-pressure conditions.

We supply seamless carbon steel pipes in all specifications of ASTM A106 Grade C, ranging from NPS ⅛″ to NPS 24″ and Sch 10 to 160. Each shipment is accompanied by a complete Material Test Certificate (MTC), and we support inspections by third-party organizations such as SGS and BV. We also provide custom processing services, including cutting, end finishing, bending, and surface treatment.

Specifications and Dimensions

# Product Name ASTM A106 Grade C Carbon Steel Pipe
1 Standard Specification ASTM A106 / A106M ( Standard Specification for Seamless Carbon Steel Pipe for High-Temperature Service )
2 Steel Grade Grade C
3 Cross-sectional Shape Round
4 Material Carbon Steel
5 Manufacturing Process Seamless
6 Outside Diameter 10.29 - 609.60 mm ( NPS ⅛″ - NPS 24″ )
7 Wall Thickness 1.24 - 59.54 mm ( Sch 10 - 160, STD, XS, XXS )
8 Length 3,000.0 - 12,000.0 mm
9 Surface Treatment Rust Removal,Painting,Coating
10 Machining Services Custom dimensions, precision cutting, threading, bending, bevel cutting, heat treatment, etc
11 Inspection Dimensional inspection, chemical composition analysis, mechanical property analysis, hydrostatic testing (optional), non-destructive testing (optional), third-party inspection (optional, SGS, BV, etc.)
11 Certificate Mill Test Certificate (MTC, EN 10204-3.1)
12 MOQ 5 tons
13 Delivery Time 15 - 20 days
14 Packaging Steel-strap bundling, standard export packaging for ocean freight, or packaging as required
15 Place of Origin China

Note: We offer customization for products with special specifications and sizes.

Chemical Composition

ElementsCMnPSSiCrCuMoNiV
Content ( wt % )≤ 0.350.29 - 1.06≤ 0.035≤ 0.035≥ 0.10≤ 0.40≤ 0.40≤ 0.15≤ 0.40≤ 0.08

Mechanical Properties

Yield StrengthTensile StrengthElongation in 2 in. [50 mm]
Transverse strip test specimen,
and small-diameter full-section test specimen		Standard round test specimen
LongitudinalTransverseLongitudinalTransverse
≥ 275 MPa [40,000 psi]≥ 485 MPa [70,000 psi]≥ 30 %≥ 16.5 %≥ 20 %≥ 12 %

Characteristics and Advantages

High-Strength Steel Pipe

Higher Mechanical Strength

Minimum tensile strength of 485 MPa and minimum yield strength of 275 MPa, both higher than Grade B. Under the same design pressure and temperature conditions, thinner wall thicknesses can be selected, reducing the pipe’s weight and material costs while saving installation space.

Seamless Steel Pipe

Seamless Construction, Suitable for Pressurized Piping

Manufactured using a seamless process with no welds, this eliminates the risk of leaks at welded joints. The uniform wall thickness provides superior resistance to internal pressure and thermal cycling fatigue, making it suitable for critical pressure piping in continuous operation.

High-Temperature Steel Pipe

Suitable for High-Temperature Applications

Defined by the ASTM A106 standard as seamless carbon steel pipes for high-temperature service, these pipes maintain stable mechanical properties even at high temperatures in hot oil, steam, and high-temperature feedwater systems. They are suitable for high-temperature, high-pressure process pipelines in power plants, oil refineries, and petrochemical facilities.

Steel Pipe Processing

Capable of Welding and Forming

Processing operations such as welding, bending, and flange forming can be performed in accordance with pipeline designs and approved procedures. During welding, attention must be paid to the material’s actual chemical composition, carbon equivalent, preheating requirements, and welding procedure qualification requirements.

High-Temperature Piping Systems

Meets a Wide Range of Industrial Transportation Needs

Suitable for high-temperature piping systems in power generation, petroleum refining, chemical production, and other applications that meet material compatibility requirements, facilitating the selection of appropriate pipe grades for engineering projects based on design conditions.

Applications

Oil and Gas Industry

Oil and Gas Industry

Refinery process piping

Pipelines for transporting crude oil, fuel oil, and hydrocarbon media

High-temperature oil transport pipelines

Pressure piping for petrochemical plants

Power and Thermal Energy Industry

Power and Thermal Energy Industry

Steam transport piping for power plants

Boiler-related piping

High-temperature feedwater and auxiliary piping

High-temperature fluid pipelines for thermal systems

Chemical and Petrochemical Industries

Chemical and Petrochemical Industries

Process piping in chemical plants

Piping for transporting non-highly corrosive chemical media

Steam and industrial utility networks

High-temperature liquid and gas transport systems

General Industry and Manufacturing

General Industry and Manufacturing

Industrial compressed air piping

Factory hot water and circulating fluid piping

Industrial heating systems

Piping for pressure-bearing machinery and equipment

Download

Technical Manual

Technical Articles

FAQ

The main differences between the two are as follows:

Grade C: Has a higher maximum carbon content (up to 0.35%, compared to 0.30% for Grade B) and higher tensile and yield strengths. Its advantage lies in its higher allowable stress, which allows for thinner wall thicknesses; its disadvantage is poorer weldability, requiring preheating and post-weld heat treatment.

Grade B: The standard grade for most high-temperature piping; it features a relatively simple welding process and is more suitable for routine on-site construction.

Get Your Custom Quote Now

We offer one-stop steel solutions, encompassing steel products and technical services, with a particular expertise in providing customized supplies for complex engineering applications. Please contact us for more detailed technical specifications.
